Fabric Specifications
- Weave: Woven white PP scrim (UV Stabilized)
- Coating: 1.2 mil/1.0 mil average (28/24 g/m2/side)
- Color: Grey
- Weight: 3.6 oz/yd2 (122g/m2) +/- 5 % (25 lb per roll)
- Thickness: 8 mil (0.20 mm)
ASTM D1777
Roll Specifications
- Roll Size: 10 Squares
- Cores: 2-inch cardboard
- Width: 48″
- Length: 250 ft/roll (76 m)
- Rolls Per Pallet: 30 Rolls
These Values are typical data and are not intended as limiting specifications.
Other sizes available upon request.
Comp. Products
- DynaClad Ultra HT Wind & Water Seal
- Butyl Tape & Sealants
- Poly-iso Insulation
- Continuous Gutter Systems
- ES-1 Rated Edge Metal Systems
- Total System Warranties
Performance
PERFORMANCE PROPERTIES
The following is typical based on ASTM and other standard testing. It should not be considered a specification.
- Grab Tensile – Warp 140 lb, 620 N / Weft 125 lb,555 N
- ASTM D-5034-09
- Strip Tensile – (N/5cm) Warp 90 lb/in (800) / Weft 80 lb/in (701)
- ASTM D-5035-11
- Tensile Elongation – Warp 24% / Weft 21%
- ASTM D-5035-11
- Tongue Tear – Warp 35 lb, 155 N / Weft 35 lb, 155 N
- ASTM D-2261-07a
- Trapezoidal Tear – Warp 40 lb, 177 N / Weft 30 lb, 133 N
- ASTM D-4533-04
- Mullen Burst – 215 psi 1481 kPa
- ASTM D-3786-01
- Moisture Vapor Transmission – 0.04 perms (0.30 g/day-m²)
- ASTM E-96-00
- Pliability – No cracking (pass)
- ASTM D-146-04
- Water Ponding – No dripping (pass)
- CAN/CSA A220.1
- Low Temperature Flexibility – -15°C (5°F) No cracking (pass)
- ASTM D-1970-01
- Puncture – 4.7 joules
- T803
- UV Weathering – UV stabilizer added to coating for improved UV resistance
- Class A Fire Resistance Rating
- ASTM E-108(2007)
- Meets the requirements of CAN/CSA A220.1
- Florida Building Code FL6645
