DMI’s Half-Round gutter provides a unique aesthetic appearance to your building and complement your roof application. Available in Galvalume®, aluminum, stainless steel, RHEINZINK®, and copper. DMI offers a full line of accessories including customized gutter support brackets, mitered corners, end caps, splice plates, expansion joints, outlets, downspouts, elbows, and downspout straps. Available in 10′-0″ lengths.


SIZE A B C D
5″ 2 1/2″ 5 1/4″ 3″ 2 1/2″ Radius
6″ 3″ 6 1/4″ 3 1/2″ 3″ Radius
7″ 3 1/2″ 7 1/4″ 4″ 3 1/2″ Radius
8″ 4″ 8 1/4″ 4 1/2″ 4″ Radius
9″ 4 1/2″ 9 1/4″ 5″ 4 1/2″ Radius
10″ 5″ 10 1/4″ 5 1/2″ 5″ Radius




Finish
DynaClad® 70% Full Strength PVDF Paint Finish, Natural Copper, Rheinzink® or Stainless Steel

Colors
Choice of over 32 Colors for Galvalume® and Aluminum


DOWNLOAD HALF-ROUND GUTTER ORDER FORM


Manage and download this product's documents with Submittal Builder
Free to registered users.

Login/Register

Advantages

The inner shape of a half-round gutter is smoother than other gutter styles, this reduces the likelihood of corrosion since there are fewer areas where wetness can hold.   In addition, their smooth surface allows waterborne debris to flow more freely instead of getting caught on rough edges or sides, which can lead to clogs over time.

Product Offerings

Offered in a large variety of materials and colors.

  • Galvalume® (22 ga. & 24 ga.) – See our color chart for standard color offering
  • Stainless Steel (22 ga. & 24 ga.)
  • Aluminum (.050, .040, & .032) – See our color chart for standard color offering
  • Rheinzink® (22 ga./.8 mm & 24 ga./.7 mm) – Go to our Rheinzink® page for more information
  • Copper (20 oz. & 16 oz.)

Support Brackets

Find the right bracket for your project.

Vertical Fascia

Non-Vertical Fascia – L-Support



Vertical Fascia – V-Support

Roof Mount

Roof Mount – Non-Vertical Fascia



Other Accessories

Perfect for giving that clean finished look to your half round gutter project.

End Caps

Inside Miter

Outside Miter
