Curved Tee-Lock

Curved Tee-Lock CR-TL25 is a structural panel which is mechanically seamed during installation. The panel is a bi-directional system by design which installs in two directions from a given starting point. TEE-LOCK provides installers more control during installation over seam layout and allows symmetry of the panel area. The one piece clip allows for unlimited expansion and contraction.

Material Minimum Radius
Steel and Aluminum 90′

DynaClad® 70% Full Strength PVDF Paint Finish

Choice of over 32 Colors



Manage and download this product's documents with Submittal Builder
Free to registered users.


Roof Assemblies

TEE-LOCK (TL25) can be applied over various roof substrates including: open framing, rigid insulation (utilizing a bearing plate under each panel clip spaced 48″ o.c., max.), steel deck and various solid substrates including plywood sheathing & nail base insulation.

Uses & Applications

Product uses include low to high slope roofing, vertical fascia, equipment screens, mansards and wall panels.  This system may also be installed on tapered and curved roof areas (radii greater than 90’).

Product Offerings

24 ga., 22 ga. Steel and .032, .040 Aluminum
Embossing and various stiffener configurations available

  • CR-TL2518 with 17.625″ o.c. seams
  • CR-TL2516 with 16″ o.c. seams
  • CR-TL2512 with 12” o.c. seams

Performance Tested

  • UL-580 Wind Uplift
  • ASTM E1592 Uniform Static AirPressure
  • ASTM E1646 Water Penetration
  • ASTM E1680 Air Leakage
  • ASTM E2140 Static Water Penetration
  • ASTM E1996 Impact Resistance & Cyclic Pressure


  • Factory Applied Hot Melt Sealant: For superior watertightness
  • Mechanically Seamed: May be installed on low slope applications
  • Bi-Directional Mechanical Seaming: Panel seaming is simplified
  • One Piece Clip: Allows for unlimited thermal expansion and contraction
  • Continuous Roll formed Lengths: Eliminates need for panel lap joints
  • Hydrostatic Seam Design: Allows for installations to 1/2:12 slopes
  • Panel design allows for individual panels to be removed and/or replaced if necessary
  • Total System Watertightness Warranties Available: For total confidence
